14. USING A LINEAR SERVO MOTOR
14 - 29
14.4.4 Permissible load to motor mass ratio when the dynamic brake is used
Use the dynamic brake under the load to motor mass ratio indicated in the following table. If the load to
motor mass ratio is higher than this value, the dynamic brake may burn. If there is a possibility that the load
inertia moment may exceed the value, contact your local sales office.
The values of the permissible load to motor mass ratio in the table are the values when the linear servo
motor is used at the maximum speed.
Servo amplifier
MR-J4-
Linear servo motor
20_ 40_ 60_ 70_ 200_ 350_ 500_ 700_
LM-H3P2A-07P-BSS0 35
LM-H3P3A-12P-CSS0 35
LM-H3P3B-24P-CSS0 35
LM-H3P3C-36P-CSS0 35
LM-H3P3D-48P-CSS0 35
LM-H3
series
LM-H3P7A-24P-ASS0 35
LM-H3P7B-48P-ASS0 35
LM-H3P7C-72P-ASS0 35
LM-H3P7D-96P-ASS0
35
LM-U2PAB-05M-0SS0 30
LM-U2PAD-10M-0SS0 30
LM-U2PAF-15M-0SS0
30
LM-U2PBB-07M-1SS0 30
LM-U2PBD-15M-1SS0 30
LM-U2
series
LM-U2PBF-22M-1SS0 30
LM-U2P2B-40M-2SS0 30
LM-U2P2C-60M-2SS0 30
LM-U2P2D-80M-2SS0
30
LM-FP2B-06M-1SS0 15
LM-FP2D-12M-1SS0 15
LM-FP2F-18M-1SS0 15
LM-F
series
LM-FP4B-12M-1SS0 15
LM-FP4D-24M-1SS0
15
LM-K2P1A-01M-2SS1 30
LM-K2P1C-03M-2SS1
30
LM-K2P2A-02M-1SS1 30
LM-K2P2C-07M-1SS1 30
LM-K2
series
LM-K2P2E-12M-1SS1 30
LM-K2P3C-14M-1SS1 30
LM-K2P3E-24M-1SS1
30
