14. USING A LINEAR SERVO MOTOR
14 - 2
14.1.2 Servo system with auxiliary equipment
CAUTION
Connecting an inappropriate linear servo motor to the CNP3 and CN2 will cause
an unexpected operation or an alarm.
POINT
Equipment other than the servo amplifier and linear servo motor are optional or
recommended products.
When using the linear servo motor, set [Pr. PA01] to "_ _ 4 _".
ࠗࡦࡁࠗ࠭
ࡈࠖ࡞࠲
(FR-BSF01)
CN5
࿁↢
ࠝࡊ࡚ࠪࡦ
P+
C
L11
L21
P3
P4
ࡄ࠰࠽࡞
ࠦࡦࡇࡘ࠲
MR Configurator2
CN3
CN8
CN1A
CN1B
CN2
W
V
U
㔚⏛ធ⸅ེ
L1
L2
L3
(ᵈ3)
(ᵈ1)
(MC)
ജ₸ᡷༀ
DCࠕࠢ࠻࡞
(FR-HEL)
ࡁࡅࡘ࠭
ㆤᢿེ(MCCB)
ਛ⛮┵ሶบ
ࡈ࠹ࠖ߹ߚߪ
MR-J3-D05ࡈ࠹ࠖ
ࡠࠫ࠶࡙ࠢ࠾࠶࠻߳
ࠨࡏࠪࠬ࠹ࡓ
ࠦࡦ࠻ࡠ߹ߚߪ
೨ゲࠨࡏࠕࡦࡊCN1B
ᓟゲࠨࡏࠕࡦࡊCN1A
߹ߚߪࠠࡖ࠶ࡊ
㔚Ḯ
(ᵈ2)
RS T
(ᵈ4)
࠾ࠕࠛࡦࠦ࠳
࠾ࠕ
ࠨࡏࡕ࠲
ࠛࡦࠦ࠳
ࠤࡉ࡞
SCALE
THM
D(ᵈ5)
Note 1.
2.
3.
4.
5.
The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P3 and P4.
A 1-phase 200 V AC to 240 V AC power supply may be used with the servo amplifier of MR-J4-70B or less. For 1-phase 200 V
AC to 240 V AC, connect the power supply to L1 and L3. Leave L2 open. For power supply specifications, refer to section 1.3.
Depending on the main circuit voltage and operation pattern, bus voltage decreases, and that may cause the forced stop
deceleration to shift to the dynamic brake deceleration. When dynamic brake deceleration is not required, slow the time to turn
off the magnetic contactor.
For the branch cable, use the MR-J4THCBL03M (optional).
Always connect between P+ and D terminals. When using the regenerative option, refer to section 11.2.
(Note 2)
Power supply
Molded case
circuit breaker
(MCCB) or fuse
(Note 3)
Magnetic
contactor
(MC)
(Note 1)
Line noise
filter
Power facto
r
improving
DC reactor
(FR-HEL)
Regenerative
option
D
(
Note
)
Personal
com
p
uter
Junction terminal
block
Safety relay or
MR-J3-D05 safety logic unit
Servo system
controller or Front axis
servo amplifier CN1B
Rear servo amplifier
CN1A or Cap
(Note 2)
Linear servo motor
Encoder
cable
Linear
encoder
