Setting the Video System
Setting the Video
System
Select “Video System” in the “Options”
menu on the menu screen.
➝For operating the menu screen, see
pages 42 to 45.
Note
• The video signal can only be set in IN-
PUT 3 or INPUT 4 mode.
• In “Auto”, images are displayed in PAL
even if PAL-N or PAL-M input signals are
received.
The video input system mode is preset to “Auto”; however, a clear picture from the con-
nected audio-visual equipment may not be received, depending on the video signal differ-
ence. In that case, switch the video signal.
When connected to PAL video equipment.
When connected to SECAM video
equipment.
When reproducing NTSC signals in
PAL video equipment.
When connected to NTSC video equipment.
PAL
SECAM
NTSC4.43
NTSC3.58
* If the input signal has interference, the screen
will be displayed with the interference.
Selecting a
Background Image
Select “Background” in the “Options”
menu on the menu screen.
➝For operating the menu screen, see
pages 42 to 45.
Selected Item
Blue
None
Description
Blue screen
Black screen
*
Setting a Background Image
This function allows you to select the image displayed when no signal is being sent to the projector.
-70
