Basic Operation
-47
Adjusting Image Prefer-
ences
Adjust the “Picture” menu on the
menu screen.
➝For operating the menu screen, see
pages 42 to 45.
Note
• Picture adjustment settings differ depend-
ing on the type of input signal.
• Some items may not be adjustable de-
pending on the combination of the INPUT
mode and “Signal Type” setting.
Contrast
Bright
Color
Tint
Sharp
CLR Temp
For adjusting the contrast level
For adjusting the brightness of an image
For adjusting the color intensity of an image
For adjusting the tones of an image
For making sharper or softer the contour of an image
For adjusting the color temperature of an image
For less contrast
For less brightness
For less color intensity
Skin tones become purplish
For less sharpness
Decreases color
temperature for warmer,
reddish, incandescent-
like images.
For more contrast
For more brightness
For more color intensity
Skin tones become greenish
For more sharpness
Increases color
temperature for cooler,
bluish, fluorescent-like
images.
Selected Item Description
\ button | button
Selecting the Gamma
Position
This function allows you to select the desired
gamma position.
Select “Gamma Position” in the “Pic-
ture” menu on the menu screen.
➝For operating the menu screen, see
pages 42 to 45.
Note
• Gamma can be adjusted in greater detail
with “Gamma” on the menu screen. See
page 52 for details.
XV_Z12000_E_US_p42_60.p65 03.9.24, 2:01 PM47
