Easy to Use Functions
-65
Switching HIGH
BRIGHTNESS MODE/
HIGH CONTRAST MODE
Press on the remote control to
select the desired mode.The mode
is switched in the order of “HIGH
BRIGHTNESS MODE”, “MEDIUM
MODE” and “HIGH CONTRAST
MODE”.
Switchable High Brightness/High Contrast Mode
This function controls the quantity of the projected light and the contrast of the image. It can
be operated using the IRIS button on the remote control.
Note
• The projector is set to the “HIGH BRIGHT-
NESS MODE” when shipped from the fac-
tory.
IRIS button
Selected Mode
HIGH BRIGHTNESS
MODE
Description
High brightness is
given priority over
high contrast.
Intermediate mode
between high contrast
and high brightness
High contrast is given
priority over high
brightness.
MEDIUM
MODE
HIGH CONTRAST
MODE
XV_Z12000_E_US_p61_65.p65 03.9.24, 2:04 PM65
