Easy to Use Functions
-73
Reversing/Inverting Projected Images
This projector is equipped with a reverse/invert image function that allows you to reverse or
invert the projected image for various applications.
Setting the Projection
Mode
Select “PRJ Mode” in the “Options”
menu on the menu screen.
➝For operating the menu screen, see
pages 42 to 45.
Selected Item
Front
Ceiling + Front
Rear
Ceiling + Rear
Description
Normal image
Inverted image
Reversed image
Reversed and inverted image
Front Ceiling+Front Rear Ceiling+Rear
Note
• This function is used for the reversed im-
age and ceiling-mount setups. See page
32 for these setups.
