CheckProblem Page
Troubleshooting
For SHARP Assistance (U.S.A only)
If you encounter any problems during setup or operation of this projector, first refer to the “Trouble-
shooting” section on pages 89 and 90. If this operation manual does not answer your question,
please call toll free 1-877-DTV-SHARP (1-877-388-7427) for further assistance. Or, send us an e-
mail at [email protected] .
Our World Wide Web address is http://www.sharpusa.com/ .
• Change the input signal type setting. 69
• The lamp indicator is blinking in red. Replace the lamp. 78
• Picture adjustments are incorrectly set. 47
• In the case of transmitting RS-232C commands from a computer 84
during standby, it takes a maximum of 30 seconds for the
computer to receive the response code. Set the response code
waiting time of the computer to 30 seconds or more.
Picture is green on
INPUT 1 or 2 COMPO-
NENT.
Picture is pink (no green)
on INPUT 1 or 2 RGB.
Picture is dark.
Picture is too bright and
whitish.
A response code cannot
be received when the
projector was attempted
to be controlled using
RS-232C commands
from a computer during
standby.
XV_Z12000_E_US_p89_96.p65 03.9.24, 2:10 PM90
