Selecting the Economy Mode
Selecting the Transmission Speed (RS-232C)
This menu allows you to adjust the transmission speed of the RS-232C connection by select-
ing the baud rate.
-72
Selecting the Transmis-
sion Speed (RS-232C)
Select “RS-232C” in the “Options”
menu on the menu screen.
➝For operating the menu screen, see
pages 42 to 45.
Note
•
Make sure that both the projector and com-
puter are set for the same baud rate. Refer to
the computer’s operation manual for instruc-
tions for setting the computer’s baud rate.
Automatic Power Off
Function
Select “Auto Power Off” in “Economy
Mode” under the “Options”
menu on the
menu screen.
• “Auto Power Off” is switched “ON” and
“OFF” by pressing .
➝For operating the menu screen, see
pages 42 to 45.
Note
•
When the Auto Power Off function is set to
“ON”, 5 minutes before the projector enters
the standby mode, the message “Enter
STANDBY mode in X min.” will appear on
the screen to indicate the remaining minutes.
•
When Auto Power Off function is set to
“OFF”, “LED” is set to “ON” automatically.
Be sure to set Auto Power Off function to
“ON” to use LED Off function. (See page 67.)
Description
When no input signal is
detected for more than 15
minutes, the projector will
automatically enter the standby
mode.
The Auto Power Off function
will be disabled.
Selected Item
(ON)
(OFF)
XV_Z12000_E_US_p66_74.p65 03.9.24, 2:06 PM72
