PACER GROUP SARASOTA
CORPORATE HEADQUARTERS
NA
TIONAL AND OEM SALES
18004249549 • FAX: 9413799015
PACER GROUP FT. LAUDERDALE
EAST COAST SALES AND
AFTER
MARKET SALES
18006345031 • FAX: 9547638062
59www.pacergroup.net
Group
PART STUD CURRENT COVER
NUMBER TYPE RATING CONFIGURATION PART NUMBER
AMPS
EPB2 (2) 3/8" 600DC BUS w/2 POSTS PKG w/2 BOOTS
EPB4-4 (4) 3/8” 600DC BUS w/4 POSTS AND 4 (#8) SCREWS EPB4-4C
EPB8-4 (8) 3/8” 600DC BUS w/8 POSTS AND 4 (#8) SCREWS
POWERBAR
Blue Sea Systems power bar is a unique high amperage power distribution bus. Constructed from tinned-
plat
ed CDA110 copper with a GE Lexan polycarbonate base. Rated at 48 volts DC maximum.
EBP4 4C
EPB84EPB44
PART STUD CURRENT COVER
NUMBER TYPE RATING CONFIGURATION PART NUMBER
AMPS
EMXB2-12 (2) 5/16” 250 BUS w/2 POSTS AND 12 (#10) SCREWS EMXBC
EMXB4 (4) 5/16” 250 BUS w/4 POSTS EMXBC
MAXI BUS BARS
EMXB212
EMXB4
EMXBC
COMMON, HEAVY DUTY, BUS BARS
Constructed from 1/4" thick nickel plate copper with nickel plated bronze
studs and durable L
exan mounted pads.
EPB3W
EPB4W
EPB7W
PART NUMBER STUD TYPE CURRENT RATING
AMPS
EPB3W 5/16", 3/8", 5/16" 500AMPS
EPB4W 5/16", (2)3/8", 5/16" 500AMPS
EPB7W 5/16", (5)3/8", 5/16" 500AMPS
