AVAILABLE AMP SIZES

ORDERING INFORMATION: Available by the piece

RATED PART

AMPS NUMBER

110 ETF-110

125 ETF-125

150 ETF-150

175 ETF-175

200 ETF-200

225 ETF-225

250 ETF250

300 ETF300

350 ETF350

400 ETF400

CLASS “T” FUSE BLOCK

FEATURES:

• Clear Lexan cover insulates

all conductive parts,

satisfying ABYC/USCG

requirements

• For use on systems up to

160V

DC

• Large 3/8" Stud Terminals

• Large heat dissipating, tin

copper, mounting blocks

• 2 (#8) accessory terminals

located on each end

P/N: EFB-T

ANL TYPE FUSES, FUSE HOLDERS

AND BLOCKS

ANL FUSES

FEATURES:

• Low voltage limiter, 32Volts AC or Less

• Interrupt Capacity: 6,000 AMPS

• Isolates faults in battery operated systems.

• Silver-plated copper links

• Link element visible through mica window.

RATED PART

AMPS NUMBER

35 EANL35

40 EANL40

50 EANL50

60 EANL60

80 EANL80

100 EANL100

130 EANL130

150 EANL150

175 EANL175

200 EANL200

225 EANL225

250 EANL250

275 EANL275

300 EANL300

350 EANL350

400 EANL400

500 EANL500

600 EANL600

ORDERING INFORMATION:

Available by the piece.

BUSSMANN 4164

FEATURES:

• Single-pole, stud terminal

• Molded thermoplastic base

• Two countersunk mounting holes on

1-in centers for #10 flat head screws

• Tightening torque is 120 in-lbs

• 125V

• L 3.38” x W 0.95” x H 1.62”

CLASS “T” FUSES

FEATURES:

• Extremely fast short circuit response

• 20,000 Ampere interrupt capacity

• UL Rated for DC applications under UL 198L

BLUE SEAS LIGHT ANL FUSE BLOCK

WITH COVER

FEATURES:

• Clear insulating cover protects

conductive components – satisfies

ABYC/USCG requirements

• 180 degree access with cover on

for 14-2/0 AWG wire

• Stainless steel studs and

fasteners prevent corrosion

• UL 94V0 black base resists high heat

• For use on systems up to 48 volts DC

• Maximum Amperage 300 Amperes DC

• Large 5/16” M8 Studs

• L 4.5” x W 1.25” x H 1.67” (Min)

P/N: EFB-ANL

-LT

BLUE SEA ANL H/D FUSE BLOCK

FEATURES:

• 750 Ampere rating achieved with

large heat dissipating, tin-plated,

copper mounting block

• Clear insulating cover satisfies

AB

YC/USCG requirements

• For use on systems up to 48 Volts DC

• Large terminals accept 5/16” or M8 ring terminals up to 4/0

• L 7” x W 2”

P/N: EFB-ANL

-HD

EFBT

P/N: EFB-ANL

ORDERING INFORMATION: Order by the piece.
