Blue Sea Systems offers a unique, long lasting, fuse block. The fuse block utilizes all nickel-plated metal
components. Beryllium copper contact clips are rated at 30 Ampere. The unique clear insulating covers
with label recesses protect all conductive parts, satisfying all ABYC/USGA requirements. Spare fuses can
also be stored in the cover. Fits AGC fuses and all other 3AG Glass fuses.
FEATURES:
• Material: Glass-filled Nylon • Clear, insulating, plastic cover with label recesses
• Maximum Amperage per Circuit: 30 Amperes • Spare fuse storage
• Maximum Amperage per Block: 100 Amperes • Nickel plated metal components
• Maximum Voltage: 32 Volts DC • Independent ground bus
NUMBER OF CIRCUITS PART NUMBER
6 EFB30-6IBC
AGC FUSE HOLDERS
WATER-RESISTANT
Accepts 18 through 12 AWG wire, 30 AMP maximum. One piece construction, recommended for use where
holder will come into contact with dust, dirt, moisture and harsh environments.
P/N: EFH-WP
MOLDED WATER-RESISTANT
A push together, water-tight, inline fuse holder, with an 8 inch, 14 or 10 AWG wire loop molded into the
assembly. Made with heat-resistant, non-breakable plastic. AGC type fuses included.
PART NUMBER WIRE AWG & FUSE TYPE
EFH-MWP30 10 AWG, 30 AMP AGC FUSE
EFH-MWP15 14 AWG, 15 AMP AGC FUSE
PANEL MOUNT “KNOB TYPE”
Recommended panel cutout .505 diameter.
Terminals: .250 quick connects.
P/N: EFH-PMKT
AGC FUSE BLOCKS
BRASS FUSE BLOCKS
Made with brass clips and screws with a common bus bar connected to the fuse clips, and an additional independent bus.
NUMBER OF PART MATERIAL
CIRCUITS NUMBER BASE CLIP/SCREW
4 EFB20-4IB BAKELITE BRASS
6 EFB20-6IB BAKELITE BRASS
8 EFB20-8IB BAKELITE BRASS
AGC TYPE GLASS FUSES
AND FUSE HOLDERS
FEATURES:
• Dimensions: 1/4" dia. By 1-1/4" long
ORDERING INFORMATION:
Order by multiples of 5.
RATED PART
AMPS NUMBER
.5 EAGC.5
1 EAGC1
1.5 EAGC1.5
2.5 EAGC2.5
3 EAGC3
5 EAGC5
7.5 EAGC7.5
10 EAGC10
15 EAGC15
20 EAGC20
25 EAGC25
30 EAGC30
IN-LINE
“
KNOB TYPE”
Spring loaded with wire included.
P/N: EFH-KT
