BUS BARS
Pacer stocks a wide variety of bus bars for many uses, including 500 and 600 AMP continuous rated power buses. Improper or
corroded buses can rob precious voltage from a circuit. In starter and anchor windlass circuits where hundreds of amps flow, this
could mean a big difference in cranking/lifting capability. Connect all high amperage cables securely.
FEATURES:
• 48 Volts DC Maximum • Tinned Plated Brass Bus • Base Material: Glass Reinforced Nylon
PART NUMBER P/N WITH BOOT STUD TYPE CURRENT RATING CONFIGURATION
WITHOUT BOOT
ESB1-1/4 ESB1-1/4B 1/4" N/A MINI POWER POST
ESB1-5/16 ESB1-5/16B 5/16” N/A* POWER POST
ESB1-3/8 ESB1-3/8B 3/8” N/A* POWER POST
ESB1-8-5/16 ESB1-8-5/16B 5/16” 150 POWER POST w/8 (#8) SCREWS
ESB1-8-3/8 ESB1-8-3/8B 3/8” 150 POWER POST w/8 (#8)SCREW
SINGLE POST BUSES
PART STUD CURRENT COVER
NUMBER TYPE RATING CONFIGURATION PART NUMBER
EMB0-6 N/A 100 MINI BUS w/6 (#8) SCREWS N/A
EMB2-5 (2) 10-24 100 MINI BUS w/2 POSTS AND 5 (#8) SCREWS EMBC
EMB4 (4) 10-24 100 MINI BUS w/4 POSTS EMBC
MINI BUSS
* Not Rated - Amperage flow is between terminals stacked on the post and is dependent on the wire and terminals used.
EMB25
EMB4
EMBC
ESBI5/16B
ESBI83/8B
EMBO6
ESBI1/4B
ESBI1/4
EMB25
EMB4
EMBO6
ESBI5/16
ESBI83/8
