CABLE CUTTERS

These economical tools can handle most cable cutting jobs easily. Curved shear edges allow for a

clean, efficient cut without compression or fraying ends. The VT63050 is capable of cutting up to 2/0

battery cable yet the cutter is only 9 1/2" long. The VT63055 is 8" long and has a compact cutting head

for use in tight areas. (Tools are not designed for cutting steel or ACSR.)

PART NUMBER DESCRIPTION

VT63050 HIGH LEVERAGE CABLE CUTTER

VT63055 COMPACT CABLE CUTTER

ORDERING INFORMATION:

Order by the piece.

VT63055

WIRE STRIPPER CUTTER

Easy to use and economical wire stripper and cutters. Overall length is 6" with a narrow nose designed

to fit into tight places. Made from hardened steel with precision ground stripping holes, gauge sizes

marked on both sides.

PART NUMBER HANDLE COLOR STRIPS STRANDED WIRE GAUGES

VT45121 YELLOW 16, 18, 20, 22, 24, 26

VT45124 YELLOW 8, 10, 12, 14, 16, 18

MULTIPURPOSE TOOLS

All purpose cutter/stripper/crimper. The VT1002 and VT1010 are specially designed to handle many

stripping and terminating functions.

PART NUMBER DESCRIPTION

VT1001 ELECTRICIAN ALL-PURPOSE TOOL

VT1002 ELECTRICIAN ALL-PURPOSE TOOL

VT1010 LONG NOSE ALLPURPOSE

ORDERING INFORMATION:

All tools are available individually.

VT1002

FEATURES:

• Strips 10-22 AWG • Knife type wire cutter

• Cuts 5 bolt sizes • Crimps insulated and non-insulated terminals

• Color coded crimping and die sizes

AUTION: Never use any pliers or cutters on live electrical circuits.

VT1010

HEAVY DUTY RATCHET CUTTER

Capable of cutting up to 3 inch in diameter cables. A high

leverage ratchet system multiplies hand force making even large

gauge cable cutting easy. Its small size (13" in length) allows it to

be used in tight, hard to reach areas and for easy storage in tool

boxes.

P/N: VT63060 cuts up to 600 mcm soft copper

P/N: VT85-0030 cuts up to 750 mcm soft copper

NOTE: These cutters are not designed to cut steel or

steel-reinforced conductors.

VT63050

VT63060

VT85-0030

VT1001
