18 /
[Maintenance Tools]
Table 2-1 lists tools necessary to replace the printed circuit boards and the units.
Table 2-1 Maintenance Tools
No.
No. 1-100 Philips
screwdriver
Q' ty Place of use RemarksService Tools
1
2
3
4
5
6
8
No. 2-200 Philips
screwdriver, Magnetized
No. 3-100 screwdriver
No. 5-200 screwdriver
Digital multimeter
Pliers
Handy cleaner
LED Head cleaner
High voltage probe
1
1
1
1
1
1
1
2~2.5 mm screws
3~5 mm screws
9 1
7 1
Transparency sheet
( thickness premeasured)
0ZZ42404301//
Stage height adjustment jig
0ZZ42423701//
-
Microdriver
2.0mm
Adjustment for Media
Thickness sensor
Adjustment for Media
Thickness sensor
Adjustment for Lever
adjust
(Media Thickness)
10
11
12
1
1
1
