130 /

Abnormal Image Flowchart No.

The entire image is faint or the color is irregular. (Figure 5.2- A ) 1

The white portion is dirty. (Figure 5.2- B ) 2

A white page is output. (Figure 5.2- C ) 3

Streaks or solid lines appear in the vertical direction. 4

(Black line, color line / black streak, color streak) (Figure 5.2- D )

White solid lines / streaks or blurred color lines / streaks appear in the vertical 5

direction. (Figure 5.2- F )

Faulty fusing (image blurs or scatters when touched) 6

Consistent abnormality (Figure 5.2- E ) 7

Color detachment 8

Color irregularity 9

Different color compared with the original. 0

5.5.3 Troubleshooting for abnormal images

Apply remedies according to the following table when printed images are abnormal as shown

below.

Figure 5.2

Faint or blurred

Vertical lines/streaks

Dirty white portion

Consistent abnormality

All white

Vertical white lines/streaks
