5-77
SCANNER/INTERNET FAX
Contents
4
Select job build mode.
(1) Touch the [Job Build] key so that it is
highlighted.
(2) Touch the [OK] key.
5
Press the [COLOR START] key or the [BLACK & WHITE START] key to scan the
first set of originals.
If the destination is an Internet fax destination, press the [BLACK & WHITE START] key.
To cancel scanning...
Press the [STOP] key ( ) to cancel the operation.
6
Insert the next set of originals and press the [COLOR START] key or the [BLACK
& WHITE START] key.
Press the [START] key pressed in step 5.
Repeat until all originals have been scanned.
To cancel scanning...
Press the [STOP] key ( ) to cancel the operation. All scanned data will be cleared.
7
Touch the [Read-End] key.
• If no action is taken for one minute after the confirmation screen appears, scanning automatically ends and the
transmission is reserved.
• The [Configure] key can be touched to change the exposure, resolution, scan size, and send size for each original
page scanned.
If the memory becomes full during scanning, a message will appear and the transmission will be canceled.
To cancel the job build function....
Touch the [Job Build] key in the screen of step 4 so that it is not highlighted.
Job
Build
Scan/Special Modes
OK
Card Shot
Slow Scan
Mode
Quick File
Erase
File
Suppress
Background
Program
Timer
Business
Card Scan
(2)
(1)
Read-EndConfigure
Place next original. (Pg.No.x)
Press [Start].
When finished, press [Read-End].
