INSTALLING THE PRINTER
STATUS MONITOR
Printer Status Monitor is a printer utility that allows general users to check the
current status of the machine on their computer screen, such as whether or not
the machine is ready to print. The Printer Status Monitor shows error
information such as paper misfeeds, printer configuration information (whether
or not a finisher is installed, etc.) as an image, the paper sizes that can be used,
and the amount of paper remaining.
Supported operating systems: Windows 98/Me/NT 4.0
*
/2000
*
/XP
*
/Server
2003
*
/Vista
*
/Server 2008
*
* Administrator's rights are required to install the software.
When the software selection screen appears in step 6 of "OPENING THE
SOFTWARE SELECTION SCREEN (FOR ALL SOFTWARE)" (page 8),
perform the steps below.
1
Click the [Printer Status Monitor] button.
The Printer Status Monitor cannot be used in the following situations:
• When the machine is connected by a USB cable.
• When printing to the machine using the IPP function.
