4-110
FACSIMILE
Contents
This section explains how to check the status of reserved transmission jobs and received faxes.
JOB STATUS SCREEN
The job status screen is displayed when the [JOB STATUS] key on the operation panel is pressed. The job status
screen shows the status of jobs by mode. When the [JOB STATUS] key is pressed, the job status screen of the mode
that was being used before the key was pressed appears.
Reserved transmissions and received faxes are referred to as jobs here.
Example: Pressing the key in fax mode
CHECKING THE STATUS OF FAX
JOBS
The job status display is in the lower left corner of the touch panel. The job status display can be touched to display the job
status screen.
Fax JobScan toPrint Job
Address
Broadcast0001 10:00 04/01 020/003 Connecting
04/01
000/004
Waiting
Broadcast
BBB BBB
AAA AAA
0123456789
10:05
04/01
000/004
Waiting
10:22
04/01
000/010
Waiting
10:30
04/01
000/010
Waiting
10:33
Set Time Pages Status
1
1
Job Queue
Complete
Detail
Priority
Stop/Delete
Internet Fax
JOB STATUS
Auto
Auto
File
Quick File
Address Review
Direct TX
Sub Address
Address Book
USB Mem. ScanFaxInternet Fax PC Scan
Sending
Special Modes
Resolution
Exposure
Original
Scan:
Scan
Send:
Standard
Auto Reception
Fax Memory:100%
8½x11
