4-51
FACSIMILE
Contents
4
Specify the orientation in which the
original is placed.
(1) Touch the appropriate [Image Orientation]
key.
If the wrong orientation is selected here, the image may
not be sent properly when using enlargement/reduction.
(2) Touch the [OK] key.
The ratio used for reduction or enlargement of the original will appear between the "Scan Size" and the "Send Size".
11x17
8½x11
Scan Size Send Size129%
Fax/Original
OK
2-Sided
Booklet
2-Sided
Tablet
Image Orientation
(2)(1)
