General Machine Settings
50
Auto clear
After a fax or copy job is completed, the machine will automatically return all
temporary copy settings or all temporary fax settings to the default settings if
60 seconds elapses without any keys being pressed on the operation panel. If
desired, you can change the amount of time that must elapse to 30 seconds
or 120 seconds, or turn auto clear off so that temporary settings are never
automatically cleared.
1 Press (or ) and then .
2 Press .
3 Press a number key to select the
desired setting:
: 30 SEC
: 60 SEC
: 120 SEC
: OFF
4 Press repeatedly to exit.
COPY
SCAN
MENU
The display briefly shows
your selection, then:
Display:
COMMON SETTING
3: KEY TONE
1: 30 SECONDS
