Scanning From a TWAIN Application
111
7. Scanning
• Note: The document glass is not
suitable for scanning books or other
bound documents (the surface to be
copied must lie flat on the glass).
Using the auto document feeder:
Adjust the document guide to the width of
your original(s), and then insert the
originals face up into the feeder.
• Up to 20 A4-size sheets can be
inserted at once. Note that some
applications may only allow you to scan
one page at a time.
• For detailed information on using the
auto document feeder and the types of
originals that can be used, see pages
62 to 64.
2 Start your TWAIN-compliant application on your computer.
3 Click the File menu and select “Select Scanner”.
• The File menu of Sharpdesk is shown below.
