Panel Management and Option

Managing panels

4) MACaddress

 SettheMACaddressforthetargetPCifyouwanttoturnitonfromthecontrollerPC.

5) FTPSetting

 Enterthe“Username”(within30alphanumericcharacters),“Password”(within30alphanumeric

characters),and“Portnumber”(1-32000)thatyousetforthetargetPCFTPsettings.

 •FTPsettingsforaddingapanelcanbesetinadvance.(

p.83)

•IfyouhaveinstalledtheViewerVersion,auniqueFTPServerwillbeinstalled,andstartedasa

service.ThedefaultTCP/IPportnumbersare20and21.Ifthisportnumberisalreadyusedby

anotherservice,changetheportnumber.TheFTPsettingsofthetargetPCClientScheduler

must use the same port number. (

p.101)

6) PowerControl

 IfyouwanttoturnthepowerofthetargetPConoroffataspeciﬁedtime,selectthe“Specifytopower

on/offthepanelthroughtheserveratthedesignatedtime”,andsetthe“Timetostart”and“Timeto

end”.(Timescanbespeciﬁedinincrementsof5minutes)

3. Click [Add] or [Cancel].

●Adding/editing a group

1. To add a group, click [Add Group].

The[AddGroup]dialogboxwillappear.

To edit a group, select the group you want to edit and click [Edit].

The[EditGroup]dialogboxwillappear.

 •Agroupcanbecreatedwithinagroup

•Itisnotpossibletocreatetwoormoregroupswiththesamename.

2. Select the parent group.

3. Enter a “Group name”.

(Namesmustbewithin50characters)

4. Click [Add] or [Cancel].
