Schedule Editor

●Deleting a schedule

Delete unnecessary schedules.

1. From the [File] menu, click [Delete Schedule].

The[DeleteSchedule]dialogboxwillappear.

2. Select the schedule folder containing the schedule.

3. From the “List of Schedule”, select a schedule, and click

[Delete].

4. Click [Yes].

The selected schedule will be deleted.

5. Click [Close].

●Changing schedule name

1. From the [File] menu, click [Properties of Schedule].

The[PropertiesofSchedule]dialogboxwillappear.

Checktheschedulenameandchangeitifyouwish.

2. Click [OK].

Creating a schedule
