Program Editor

5. Set “Scrolling.”

Set the scroll direction and speed of scroll messages.

1) Selectthe“Direction”from“Leftward,”“Rightward,”

“Upward”and“NoMove”optionbuttons.

 •Ifthe“Vertical”optionbuttonisselectedin

“MessageFormat,”the“Leftward”or“Rightward”

option button cannot be selected.

•If“NoMove”isselected,scrollmessagesaredisplayedatthecenterofthespeciﬁedrangelineby

line. (The portion that is outside of this range is not displayed.)

2) Dragthe“Speed”slidertotheleftorrighttosetthescrollspeed(10stepsavailable).

 •Evenifthescrollmessagespeedissetatthesamevalue,theactualscrollspeedmaydiffer

dependingontheperformanceofthePC.

•Whenthe“UseTransparent”checkboxischecked,thescrollspeedmaybelowercomparedwith

thatofopaquescrollmessages.Itisrecommendedthattestsbeconductedbyactuallydisplaying

scroll messages before operation.

Settingstobemadewhenthe“NoMove”optionbuttonisselected

3) Set“DisplayTimeofEachLine.”(0to9999seconds)

Scroll messages are displayed line by line. Set the display time.

4) Setwhethertoperformfade-inandfade-out.

 Todisplayscrollmessagessothatthecurrentlydisplayedscrollmessagefadesoutandthenextscroll

messagefadesinwhenswitchingbetweenscrollmessages,checkthe“UseFadingin/outWhenTelop

Switches.”checkbox.

If fade-in/fade-out scroll messages are located on a video, the desired effect may not be obtained.

6. Click [Save Scroll Message] from the [File] menu.

Or click

The[SaveAs]dialogboxwillappear.

7. Enter a new name in “File Name” and click [Save].

Thecreationofthescrollmessageﬁleisnowcomplete.

Creating programs
