Status Monitoring Tool

3) Group tree

Displays groups registered in Panel Management.(

p.78)

Whenagroupisselected,allthepanelsthatbelongtoit(exceptforpanelssetwithoutstatusacquisition)are

displayed in the panel list.

When“(Selectallpanels)”isselected,allpanels(exceptforpanelssetwithoutstatusacquisition)aredisplayed

in the panel list.

4) Panel list

Displaysalistofallpanelsintheselectedgroupsinthegrouptree(exceptforpanelssetwithoutstatus

acquisition).

Panel icons and thumbnails change according to panel status.

Panel icon/thumbnail Description

DisplayedwhenthestatusesofthepanelandthetargetPChavenotbeenacquired.

DisplayedwhenthereisnoresponsefromthetargetPC.

DisplayedwhenthereisaresponsefromthetargetPC,butscreencapturesofthe

currentlydisplayedscreencannotbeacquired.

(Exampleimageonly)

This warning icon will appear

when there is an error in

acquiringIDPstatus(e.g.

power-off, hardware error,

etc.).

DisplayedwhenthereisaresponsefromthetargetPCandscreencapturesofthe

currentlydisplayedscreencanbeacquired.

*Thumbnailsofacquiredscreencaptureswillbedisplayed.(Itdiffersdependingon

thedisplayofthetargetPC.)

*Toacquireanimagecaptureofthescreen,check“Acquisitionofscreencapture

displayingbycontrollerPC”inthe[Settingofoperationenvironment]dialogbox.

(Fp.105)

The main Status Monitoring Tool window
