15-55
Chapter 15: Appendix
15
(8) Installation of a ground terminal for a coaxial cable
A method for installing a grounding terminal for a coaxial cable is shown below. Set up a single
ground point (class 3 or better grounding) using a ground terminal (G-TM).
Ground a coaxial cable at any one point.
Ground terminal (G-TM)
Class D or better
grounding
