Chapter 15: Appendix
15
(7) Installation of a transceiver cable
An example of how to install a transceiver and transceiver cable is shown below.
An example of how to install parts on a wall
An example of how to install parts in the ceiling and below the floor
An example of how to install a transceiver and transceiver cable on a wall
An example of how to install a transceiver and transceiver cable
Example of an installation on a wall (1)
Wiring duct
(metal or plastic)
Saddle
Transceiver cable
Wooden
board
Coaxial cable
(160 x 130 x 1.0)
