15-5
Chapter 15: Appendix
15
15-2 Examples of system configurations
[1] Small scale configuration
Using a single, multi-port transceiver or hub, you can construct a network system connecting a few
devices.
Examples of small scale configurations
Twisted pair cable [UTP: Category 5]
(Maximum cable length: 100 m)
Multi-port transceiver
AUI cable
(Maximum cable length: 50 m)
(a) Using a multi-port transceiver
(b) Using a hub
Hub
