14-5
Chapter 14: Specifications
14
Item Specifications
Communication control method Master-less token method
Number of stations supported Maximum 254
Communication function
Cyclic transfer (n: n, 8K bits + 8K words)
Message transfer (1: 1, 1: n)
Maximum data length of one frame is 1K bytes
105
33.5
250
6
5
116
(Unit: mm)
Basic rack panel
JW-50FL
S0
S1
S2
S3
S4
S5
S6
S7
LNK
TX
RX
DC12V
TEST
PER
HER
P
R
O
G
R
A
R
E
M
M
10B5
10B-T
12VIN
(＋)
(−)
FG
RESET
(2) FL-net specifications
[3] External dimension drawings
