Sharp VL-E40S Technical Information Page 90
- Page / 158
- Table of contents
- BOOKMARKS
Rated. / 5. Based on customer reviews
ForThinkPadEdge14"andE40:
1
2
2
3
3
3
3
4
StepScrew(quantity)Color
Torque
1
M2×2mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgfcm)
3
M2×5mm,wafer-head,nylon-coated(4)
Black0.181Nm
(1.85kgfcm)
1170Systemboardassembly
Importantnoticesforhandlingthesystemboard:
Whenhandlingthesystemboard,bearthefollowinginmind.
•Thesystemboardhasanaccelerometer,whichcanbebrokenbyapplyingseveralthousandsofG-forces.
Note:Droppingasystemboardfromaheightofaslittleas6inchessothatitfallsatonahardbench
cansubjecttheaccelerometertoasmuchas6,000G'sofshock.
•Becarefulnottodropthesystemboardonabenchtopthathasahardsurface,suchasmetal,wood,or
composite.
•Ifasystemboardisdropped,youmusttestit,usingPC-DoctorforDOS,tomakesurethattheharddisk
driveActiveProtectionSystem
TM
stillfunctions(seebelow).
Note:IfthetestshowsthatharddiskdriveActiveProtectionSystemisnotfunctioning,besureto
documentthedropinanyrejectreport,andreplacethesystemboard.
•Avoidroughhandlingofanykind.
•Ateverypointintheprocess,besurenottodroporstackthesystemboard.
•Ifyouputasystemboarddown,besuretoputitonlyonapaddedsurfacesuchasanESDmator
conductivecorrugatedmaterial.
Afterreplacingthesystemboard,runPC-DoctorforDOStomakesurethatharddiskdriveActiveProtection
Systemstillfunctions.Theprocedureisasfollows:
84HardwareMaintenanceManual
