Removalstepsofthepalmrestassemblywithcables
1
1a
1
1
1
1
1
2
2
StepScrew(quantity)Color
Torque
1
M2×8mm,wafer-head,nylon-coated(5)
Black0.181Nm
(1.85kgf-cm)
1a
M2×5mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
3
3
4
70HardwareMaintenanceManual
