Fordiscretefanassembly
b
b
a
a
a
Forintegratedfanassembly
b
a
a
1070Microprocessor
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1030Thermalcover”onpage59
•“1060Fanassembly”onpage62
Attention:Themicroprocessorisextremelysensitive.Whenyouservicethemicroprocessor,avoidany
kindofroughhandling.
Chapter8.RemovingorreplacingaFRU65
