Sharp VL-E40S Technical Information Page 88
- Page / 158
- Table of contents
- BOOKMARKS
Rated. / 5. Based on customer reviews
6
6
1160Topshieldingassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1020Opticaldriveortravelcover”onpage58
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
•“1150LCDunit”onpage79
82HardwareMaintenanceManual
