81
STOPPING A SCAN JOB BEING
TRANSMITTED OR WAITING TO BE
TRANSMITTED
Follow the steps below to stop a job that is being transmitted or is waiting to be transmitted.
1
Press the [JOB STATUS] key.
2
Select the job that you wish to stop.
(1) Touch the mode key of the job to be
stopped.
(2) Touch the key of the job to be stopped.
(3) Touch the [Stop/Delete] key.
3
Touch the [Yes] key.
If you do not want to stop the selected job...
Touch the [No] key.
Printing of a received Internet fax cannot be stopped.
JOB STATUS
Address Set Time
Complete
Priority
Stop/Delete
Internet Fax
Job Queue
Broadcast0001 10:00 11/01 000/010 Connecting
AAA AAA 10:05 11/01 000/005 Waiting
BBB BBB 10:22 11/01 000/004 Waiting
CCC CCC 10:30 11/01 000/010 Waiting
1/1
Pages Status
Detail
Fax JobScan to
Print Job
(1) (1)(3)(2)
Delete the job?
BBB BBB
No Yes
10:22 11/01
