103
SCANNING MANY ORIGINALS AT ONCE
(Job Build)
When you have a large number of originals to transmit, this function lets you separate the originals into sets. The sets
are scanned in the automatic document feeder one set at a time and then sent together as a single transmission. Use
this function when the number of originals that you wish to scan exceeds the maximum number of sheets that can be
inserted in the automatic document feeder at once.
When scanning originals that are separated into sets, scan the set that has the first page first. The settings that you
select for the first set can be used for all remaining sets.
When using USB memory mode, connect the USB memory device to the machine before performing the procedure below.
1
Insert the originals face up in the
document feeder tray.
Place the originals face up. Insert the originals all the way into
the document feeder tray. The stack must not be higher than
the indicator line.
2
Select the mode that you wish to use.
(1) Touch the [Mode Switch] key.
(2) Touch the key of the mode that you wish to
use.
3
Touch the [Special Modes] key.
11
101
1
Originals
Originals are
scanned in
separate sets
Transmission
11
Indicator
line
Quick File
File
Special Modes
Address Entry
Address BookFax
Data EntryPC Scan
USB Mem. Scan
Internet Fax
Scan
Mode Switch
Send Settings
Settings
(1) (2)
Quick File
File
Special Modes
Address Entry
Resend
Scan
A4
Send
Address Book
Scan
Mode Switch
Settings
Send Settings
Ready to send.
Auto
