OPTIONAL EQUIPMENT
10-BIN SORTER
(
SF-S18
)
20-BIN SORTER
(
SF-S15
)
There are two sorter modes for different copying jobs: one sorts
copies into sets matching the sequence of originals and the second
groups copies from different originals into separate sort bins.
The maximum allowable number of copies varies with the selected
mode.
The number of copies will be automatically reset to the maximum
number allowable for the selected mode when copying begins if this
maximum is exceeded.
NOTES:
●
To install the 20-bin sorter (SF-S15), an optional stand/500-sheet
paper drawer (SF-D20), stand/1000-sheet paper drawer (SF-D21)
or an equivalent stand must be installed.
●
The bin intervals of the 10-bin sorter (SF-S18) are narrow for space
conservation. When copying from an optional document feeder
(ADF or RADF) is completed or the CLEAR ALL (
) or the sorter
bin access key is pressed in the document glass mode, the bins will
move three at a time and the space between them will become
larger so that copies can be easily taken out. This bin access mode
can be disabled using user program No. 7. See page 34, USER
PROGRAMS.
CAUTION
Do not put pressure on the sorter or subject it to undue force.
PART NAMES
SF-S18 SF-S15
10-bin sorter (SF-S18)
20-bin sorter (SF-S15)
Top cover
Sort bins
Sort bins
Bin access key
Sorter lock lever
