OPTIONAL EQUIPMENT
STAPLE TEAR line
Staple cartridge replacement
The CHECK STAPLER indicator will blink when the staple cartridge
is empty and the copier is in the STAPLE SORT mode. Replace the
staple cartridge as follows.
●
If there are still many staples left, then staples have jammed in the
stapler. See page 76.
SF-S54N 10-bin staple sorter
1
Open the stapler cover.
2
Lifting the green release lever, remove the staple
cartridge from the stapler.
●
A few staples will be left in the cartridge. Remove and discard
them.
3
Check that the first staple in the new cartridge is at the
tip of the cartridge.
●
If the first staple is not at the tip, pull it to the tip. If any staples
are protruding past the cartridge tip, tear them off at the STAPLE
TEAR line and align the first staple with the tip.
●
A cartridge holds 5,000 staples.
4
Push the new staple cartridge in until it clicks in place.
5
Close the stapler cover.
●
The stapler feeds staples automatically.
●
To check that the stapler works properly, copy an original and
staple it.
10-BIN STAPLE SORTER (SF-S54N)
10-bin staple sorter (SF-S54N)
