Sharp SF-2530 Specifications download pdf (Page 53)

GENERAL INFORMATION

SPECIFICATIONS

Specifications

COPIER

Type Desktop

Copy system Dry, electrostatic transfer system

Originals Sheets, bound documents

Original sizes Max. 11" x 17"

Copy sizes Max. 11" x 17", min. 5-1/2" x 8-1/2"

Image loss: Max. 5/32" (4 mm) (leading and trailing edges)

Copying speed 30 copies/min. (8-1/2" x 11")

(at 100% copy ratio) 23 copies/min. (8-1/2" x 11"R)

18 copies/min. (8-1/2" x 14")

16 copies/min. (11" x 17")

Continuous copy Max. 99 copies; subtractive counter

First-copy time Approx. 4.1 sec.

Warm-up time Approx. 60 sec.

Copy ratio Variable: 50 to 200% in 1% increments, total 151 steps

Fixed presets: 50%, 64%, 77%, 95%, 100%, 121%,

129%, 141%, 200%

Exposure system Moving optical source, slit exposure

(stationary platen) with automatic exposure function

Copy paper feed Choice of one or two 500-sheet automatic feed paper

trays; one manual feed tray with 50-sheet automatic

feed capability

Fusing system Heat rollers

Developer system Magnetic brush development

Light source Halogen lamp

Required power supply AC 120V, 60 Hz, 12 amperes

Power consumption Max. 1.45 kW
