7

8. Pull the finisher platform about half way out,

then loosen the screw on the locking piece (

!

:

viewed from the opposite direction) so that it

drops through the slot below it. This keeps the

platform from moving while you attach the

finisher to it.

9. Position the finisher on the stand and attach

it with two screws from the back.

10. Lift the locking piece back up and tighten the

screw firmly. Be sure it’s out of the way and

the screw is tight—otherwise the platform

will not move freely.

11. Install the stacker, making sure the hooks

are firmly engaged and that the lever on the

finisher is positioned above the stacker (

!

).
