TROUBLESHOOTING AND MAINTENANCE
158
3
Gently pull the TD (Toner/Developer)
cartridge out while pressing the lock
release button.
4
Remove the TD (Toner/Developer) cartridge from the bag. Hold
the cartridge on both sides and shake it horizontally four or five
times. Hold the tab of the protective cover and pull the tab to
your side to remove the cover.
5
While pushing the lock release
button, gently insert the TD (Toner/
Developer) cartridge until it locks
into place.
• After removing the TD cartridge, do not shake it or tap on it. Doing so
may cause toner to leak from the cartridge. Put the old cartridge
immediately in the bag contained in the box of the new cartridge.
• Dispose of the old TD cartridge in accordance with local regulations.
Lock release button
4 or 5 times
Lock release button
