114

SCANNING USING THE KEYS ON THE MACHINE

When scanning is performed by this method, Scan to USB, Network Scan and

scanning through the Button Manager can be selected.

Scanning from the operation panel of the machine

Using the Scan to USB Function

Press the [MODE SELECT] key to select

scanner mode.

The "SCAN" indicator lights up to indicate that

scanner mode is selected and the "SCAN USING:

USB/NETWORK" is shown on the display. Then

press [OK] to enter Scan to USB mode.

Place the original. (p.22)

Press the [OK] key and then [ ] key ( )

or [ ] key ( ) to select the desired

original size to scan.

Press the [OK] key and then [ ] key ( ) or [ ] key ( ) to

select the color mode (COLOR, GRAY and B/W).

(When B/W mode is selected.)

Press the [EXPOSURE ( )] key to select the

original type.

The original image type changes as follows each

time the [EXPOSURE ( )] key is pressed:

"AUTO" ( ) → "TEXT"( ) → "PHOTO"( ).

If the machine is in copy mode, press the [MODE SELECT] key to

switch to scanner mode and clear the previously set copy settings.

SCAN USING:

USB/NETWORK

ORIG. SIZE ENTER

TEXT

| | | | |
