5-22

SADDLE STITCH FINISHER

Insert the staple box.

Push the staple box until it

clicks into place.

Push back the stapler section.

■ Staple jam removal

Open the front cover.

Turn roller rotating knob C as shown in the

illustration until a blue indication is seen.

Remove the paper from the stapler

compiler.

Open the saddle stitch section cover (when

the saddle stitch function is used).

Remove the misfed paper.

Close the saddle stitch section cover.

Open the saddle stitch section cover (when

the saddle stitch function is used).

Turn roller rotating knob A in the direction

of the arrow to move the staple unit to your

side.

Blue

Roller rotating

knob C

Close the front cover.

NOTE

Execute test printing in the staple sort mode to ensure

that stapling is performed properly.

Roller rotating knob A

Staple unit
