Quick Start Guide
System Map: LCD Panel Open - Model A 1 - 7
1
System Map: LCD Panel Open - Model A
Figure 1 - 2
LCD Panel Open - Model A
1. Built-In PC Camera
2. PC Camera LED
3. LCD
4. Power Button
5. Top Case LED
Indicators
6. Airplane Mode
Button
7. GPU Button
8. Speakers
9. Keyboard
10. Built-In Microphone
11. Touchpad & Buttons
12. Fingerprint Reader
Sensor (Factory
Option)
3
5
1
8
9
11
7
6
4
8
4
12
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines above.
2
10
7
6
12
- V13.3.00 1
- Trademarks 3
- R&TTE Directive 4
