Upgrading The Computer
6 - 14 Upgrading the Optical (CD/DVD) Device
6
Removing the Optical Device Drive for Model A Computers
1. Turn off the computer, and turn it over and remove the battery and primary hard
disk bay cover (see pages 6 - 9 & 6 - 5).
2. Remove the screw at point , and use a screwdriver to carefully push out the
optical device at point .
3. Reverse the process to install the new device.
4. Replace the component bay cover (see page 6 - 7).
Figure 6 - 9
Removing the
Optical Device
(Model A)
1
2
1
2
2
