REMOVING MISFEEDS

Turn the M8 knob in the direction of the

arrow.

Grasp the M9 lever and pull out the unit.

Pull the unit out until it stops.

Remove the misfed paper.

Open the M10 lever in the direction of

the arrow.

Remove the misfed paper.

After removing the paper, return

the M10 lever to its original

position.

Open the M11 lever in the direction of

the arrow.

Remove the misfed paper.

After removing the paper, return

the M11 lever to its original

position.

Replace the unit and close the cover.

Before performing step 7, be sure to turn the M8 knob.

If you perform step 7 without turning the knobs, the

paper may tear and torn pieces may remain in the

machine.
