7-17
CHAPTER7
OPTIONAL EQUIPMENT
Finisher (AR-FN3)
FINISHER (AR-FN3)
3
Remove the misfed paper.
●
Turn the roller rotating knob in the direction of the arrow to assist
in removing the paper.
4
Close the transport.
5
Remove the misfed paper from the inside of offset tray
by raising the shutter as shown.
●
Remove the misfed paper from the paper transport area.
Roller rotating knob
