MISFEED REMOVAL
2-19
2
Misfeed in the paper feed area
Misfeed in the 500 sheet paper drawer
1
Open the upper side cover.
Push the lever upward
and gently open the
cover.
2
Remove the misfed paper.
Be careful not to tear the
misfed paper during
removal.
3
If misfed paper is not found in step 2, pull out
paper tray 1 and remove the misfed paper.
Be careful not to tear the
misfed paper during
removal.
4
Gently close the paper tray.
Push the tray firmly all
the way into the
machine.
5
Gently close the upper side cover.
After closing, confirm
that the misfeed
message has been
cleared and the normal
display appears.
Misfeed in the bypass tray
1
Remove the misfed paper from the bypass
tray.
Be careful not to tear the
misfed paper during
removal.
2
After removing the misfed paper, open
and close the duplex bypass/inverter unit
to reset.
Grasp the finger hold
and gently open the unit.
After closing, confirm that
the misfeed message
has been cleared and the
normal display appears.
If the duplex bypass/
inverter unit is not
installed, close the side
cover in the same way.
NOTE
Paper misfed from a paper tray may be extending out of the tray into the right side cover area. In this case if the
tray is drawn out of the machine, the paper may become torn and difficult to remove. To prevent this from
happening, always open the right side cover first and remove the misfed paper if it is extending into that area.
NOTE
If paper is loaded in the bypass tray, temporarily
remove the paper and close the bypass tray before
opening the side cover.
NOTE
The misfeed may have occurred inside the machine.
Check carefully and remove it.
