<P=002>
Power lead
Plug the power lead into a 120 V,
60 Hz, grounded (3-prong) AC outlet.
Press the power switch to turn on the
power.
Trays
OFF 0
ON |
Attach the original document OUT
tray by inserting the tabs into the
holes in the fax as shown.
Attach the received document tray by
inserting the tabs into the holes in the
fax as shown.
ASSEMBLY AND CONNECTIONS
1-6 INSTALLATION
