6-2 User’s Guide

Navigating the EWS

Embedded Web Server

Navigating the EWS

The EWS interface consists of a left-navigation area and a display area. Use the left-navigation

area to locate the desired items and make any configuration changes in the display area.

After each selection in the EWS, you must press the Submit button for the request to take effect.

The Update button refreshes the screen to show you the current status of the displayed

functions.

Left-navigation area Display Area
