2-54
PRINTING
4
Select the [Print and Delete] key or the
[Print and Save] key.
• If the [Print and Delete] key is selected, the files will be
automatically deleted after printing.
• If the [Print and Save] key is selected, the files will be saved
after printing.
• Output settings, 2-sided printing, paper size, the number of
copies, and other settings can be selected. For more
information, see "PRINT SETTINGS SCREEN" (page 2-56).
• If print settings are changed when a stored file is printed, the only changed setting that can be stored is the number of
copies.
• The printing speed may be somewhat slow depending on the resolution and exposure mode settings of the stored file.
OKBACK
